StateSolid
3.85V 34Ah Prismatic Solid State Battery
3.85V 34Ah Prismatic Solid State Battery
Key Features & Specs
| Capacity | 34Ah |
| Voltage | 3.85V |
| Energy Density | ≥260Wh/kg |
| Dimension | 10±0.3mm (Thickness) x 106±1mm (Width) x 210±1mm (Length) |
| Weight | 503±10g |
| Cycle Life | ≥200 cycles |
| Operating Temperatures | -20℃ to 55℃ (discharge), 0℃ to 45℃ (charge) |
| Safety | Over-discharge, over-charge, short-circuit, and vibration resistant |
| Discharge Energy | 130.9Wh |
| Internal Resistance | ≤3mΩ |
| Charge Cut-off Voltage | 4.4V |
| Discharge Cut-off Voltage | 3.0V |
| Continuous Discharge Current | 10C |
| Maximum Pulse Discharge Current | 15C (for <3s) |
| Storage Temperature | -20℃ to 25℃ for up to 1 year |
Share
Description
Harness the power of advanced energy storage with the StateSolid 3.85V 34Ah Prismatic Solid State Battery. Featuring cutting-edge solid-state technology, this battery delivers superior performance, safety, and longevity. Ideal for demanding applications, it offers high energy density and dependable power. Perfect for electric vehicles, portable electronic devices, and energy storage systems, this battery exemplifies efficiency and reliability.
Safety Features:
- No risk of fire or explosion during over-charge, over-discharge, short-circuit, heavy impact, and acupuncture tests.
- Designed to withstand high and low temperature shocks, heating additive tests, and crushing tests.
Applications:
- Electric Vehicles
- Portable Electronic Devices
- Energy Storage Systems
