3.85V 23Ah Prismatic Solid State Battery
3.85V 23Ah Prismatic Solid State Battery
Key Features & Specs
| Capacity | 23Ah |
| Voltage | 3.85V |
| Energy Density | ≥260Wh/kg |
| Dimension | 12±0.3mm (Thickness) x 76±1mm (Width) x 180±1mm (Length) |
| Weight | 339±10g |
| Cycle Life | ≥200 cycles |
| Operating Temperatures | -20℃ to 55℃ (discharge), 0℃ to 45℃ (charge) |
| Safety | Over-discharge, over-charge, short-circuit, and vibration resistant |
| Discharge Energy | 88.6Wh |
| Internal Resistance | ≤3mΩ |
| Charge Cut-off Voltage | 4.4V |
| Discharge Cut-off Voltage | 3.0V |
| Continuous Discharge Current | 10C |
| Maximum Pulse Discharge Current | 15C (for <3s) |
| Storage Temperature | -20℃ to 25℃ for up to 1 year |
Share
Description
Elevate your energy storage solutions with the StateSolid 3.85V 18Ah Prismatic Solid State Battery. Built with cutting-edge solid-state technology, this battery offers outstanding performance, enhanced safety, and exceptional durability. Designed for high-demand applications, it provides superior energy density and reliable power. Perfect for electric vehicles, portable devices, and energy storage systems, this battery is the epitome of efficiency and safety.
Safety Features:
- No risk of fire or explosion during over-charge, over-discharge, short-circuit, heavy impact, and acupuncture tests.
- Designed to withstand high and low temperature shocks, heating additive tests, and crushing tests.
Applications:
- Electric Vehicles
- Portable Electronic Devices
- Energy Storage Systems
