3.7V 30Ah Prismatic Solid State Battery
3.7V 30Ah Prismatic Solid State Battery
Key Features & Specs
| Capacity | 30Ah |
| Voltage | 3.7V |
| Energy Density | ≥275Wh/kg |
| Dimension | 11±0.3mm (Thickness) x 90±1mm (Width) x 190±1mm (Length) |
| Weight | 403±10g |
| Cycle Life | ≥200 cycles |
| Operating Temperatures | -20℃ to 55℃ (discharge), 0℃ to 45℃ (charge) |
| Safety | Over-discharge, over-charge, short-circuit, and vibration resistant |
| Discharge Energy | 111Wh |
| Internal Resistance | ≤3mΩ |
| Charge Cut-off Voltage | 4.2V |
| Discharge Cut-off Voltage | 2.5V |
| Continuous Discharge Current | 10C |
| Maximum Pulse Discharge Current | 15C (for <3s) |
| Storage Temperature | -20℃ to 25℃ for up to 1 year |
Share
Description
Experience unparalleled energy storage with the StateSolid 3.7V 30Ah Prismatic Solid State Battery. Utilizing state-of-the-art solid-state technology, this battery delivers exceptional performance, safety, and longevity. Ideal for demanding applications, it ensures high energy density and reliable power. Perfect for electric vehicles, portable electronic devices, and energy storage systems, this battery represents the pinnacle of energy efficiency and safety.
Safety Features:
- No risk of fire or explosion during over-charge, over-discharge, short-circuit, heavy impact, and acupuncture tests.
- Designed to withstand high and low temperature shocks, heating additive tests, and crushing tests.
Applications:
- Electric Vehicles
- Portable Electronic Devices
- Energy Storage Systems
